AC-MX1616-AUHD_18G a ešte jeden člen rodiny 18G_HDMI2.0a/b prepínačov...

Pridal: Pridané: 28.7.2017 04:45:00 Počet zobrazení: 289

28 Júl 2017

týmto produktom sme vyčerpali možnosti rozmeru 19" * 1U.... podaril sa nám pekný prepínač 16*16 s plnou podporou HDCP2.2 a HDMI2.0a/b, a plnou podporou HDR10 a 12bit, Dolby Vision... SPDiF Audio extrahované na kždom výstupe, každý vástup má zabudovaný Up-Down Scaler, EDID management, riadenie s IR, RS232, podpora pre riadiace systemy C4, Crestron, Elan atď... na prednom paneli zabudovaný LCD monitor...

AC-MX1616-AUHD_18G a ešte jeden člen rodiny 18G_HDMI2.0a/b prepínačov...







AC-MX1616-AUHD

18Gbps True 4K60 4:4:4 16x16 Matrix (Ultra Low Profile)

• HDMI 2.0(a/b)
• 18Gbps Bandwidth Support
• Video Support max. UltraHD*2160P*60Fps@24bit YCBCr 4:4:4 Support
• VESA Support max. 5k 5320*3200
• Ultimate HDR Support (HDR 10 & 12 Bit)
• Dolby Vision, HDR10+ and HLG Support
• HDCP 2.2 (and all earlier versions supported)
• Simple setup with front panel control screen
• WebOS for simple connectivity and control/management
• Ultra-Low Profile (1U)
• Fast Switching
• Advanced EDID Management
• IR, RS-232 and LAN Control Options
• Digital Coax Audio Out (6CH PCM, DD, DTS)
• Driver Support for Crestron, C4, RTI, ELAN and more!!!
• Extracted Audio Now Has 3 Operating Modes. Bound to Input, Bound to Output, or Independent Matrix

1



2The AC-MX1616-AUHD is a true high bandwidth powerhouse. Supporting the full HDMI 2.0a/b specification and supporting every flavor of HDR, this matrix will ensure you can get the most out of the system. This unit supports uncompressed HDR formats Including HDR, HDR10, HDR10+, Dolby Vision, HLG, BBC and NHK. All of them are supported in up to 4K 60Hz and up to 12 Bit Deep Color. All color space compression is compatible.

Our unique design has allowed us to improve high bandwidth switching speeds. Average speeds of less than 3 seconds – this is an industry best for this advanced level of actual uncompressed, high bandwidth w/ HDR switching. Maximum compatibility and speed improve the customer experience immensely.

The sleek, low-profile and high-density design make for a sleek machine that saves you valuable space in the rack room. This combined with a OLED setup screen on the front that makes setup and management a breeze will make this a staple in your large demanding installations!

________________________________________
Key Benefits of using the AC-MX1616-AUHD
Uncompressed ~
Uncompressed base-band video means that what you put in it what comes out. This allows the integrator ultimate control to use any infrastructure they want. Use pure fiber like Cleerline, Bullet Train Cables (Long Haul, Shout Haul), or 18Gbps HDBaseT Extenders (AC-EX40-444) to get the full bandwidth and full picture!

Ultimate HDR Support ~
This matrix supports all flavors of HDR in all formats. Including HDR, HDR10, HDR10+, Dolby Vision, HLG, BBC and NHK. All of them are supported in up to 4K 60Hz and up to 12 Bit Deep Color. All color space compression are compatible.

Extreme EDID Management ~
With 29 on board EDID's, including HDR EDID's, not getting a picture is simply a thing of the past. You can manage the input side of the switch by selecting a preloaded EDID. It also has the ability to INSTANTLY read an EDID from any connected display and apply it to the desired input, all with the push of a button. Goodbye EDID problems...

Front Panel Screen ~
Make setup a breeze! The front panel allows you to do basic setup including; EDID, Audio, Matrixing and network. All without connecting a PC or hooking anything up. This additional mode of control is a welcome resource on the job site.

WebOS~
Full matrix control is available on the internal WebOS - Simply plug the matrix into the network and punch in the default IP (192.168.1.239) or use DHCP to connect to a full control system! The WebOS is designed with mobile devices in mind, so feel free to use you phone or tablet for real-time control.

Fast Switching ~
Our unique design has allowed us to improve high bandwidth switching speeds. Average speeds of less than 3 seconds – this is an industry best for this advanced level of actual uncompressed, high bandwidth w/ HDR switching.

Audio De-Embedding ~
Our unique Audio De-Embedding allows:
• It features 16 digital coax outputs for with support for 6CH LPCM, Dolby Digital, DTS.
• Extracted audio routing options include
1. Bind to output (extracted audio witches with the video, this is the default mode)
2. Bind to input (extracted audio is fixed to the corresponding input by the same number)
3. Independent (extracted audio can be routed however you like and there are commands to allow it to function as a separate matrix)
• Need advanced audio management? For down-mixing check out AC-ADM-AUHD or AC-ADM-COTO!

Ultra-Low Profile ~
With the AC-MX1616LP-AUHD you save valuable rack space. The unprecedented 1U, High Density, design you get to save massive amounts of space in the rack. For even more space saving – Look at our extenders (AC-EX70-UHD, AC-EX40-444) that have their very own rack mount and power supply for up to 8 extenders at a time!

Mixed System? Need to Down-Scale? ~
The AC-MX1616-AUHD is designed to work seamlessly with two AVProConnect Scaling Devices so you can maximize your sources output and scale to older displays:
• AC-SC1-AUHD – Add these just before the legacy display to downscale to non-HDR 4K or 1080P. These will work in ANY infrastructure you select for the job. Don't forget to ask about special pricing on AC-SC1-AUHD when you purchase this Matrix!
• AC-EX40-444 & AC-EX70-444 –
• If you use these 18Gbps HDbaseT Extenders over category cable for an extension method

Matrix Switch Application

3

• Definition –
• Matrix switchers provide the ability to route any input to any output or to multiple outputs at any time. Depending on the model, a matrix switcher can route HD, UHD or SUHD content in this manner. Additionally, since most venues have audio zones and video zones the requirement to breakout or strip off the audio in often necessary and has become almost a standard feature on matrix switches.
• Control –
• Matrix switches are generally controlled via 3rd party controller like Control 4, RTI, Crestron and others. Many integrators want ready made drivers for their control system to make programming and deployment easier.
• Who uses them? –
• At the heart of almost every custom install is a matrix switch to ease routing and distribution of signals throughout the install including Audio, Video and Control – so, you have a product that can compete on price, performance, compatibility, and control.
• Matrix Switches are used widely in both Commercial and Residential Applications

________________________________________
Full Feature Set
• HDMI 2.0(a/b)
• 18Gbps Bandwidth Support
• 4K60 4:4:4 Support
• Ultimate HDR Support (HDR 10 & 12 Bit)
• Dolby Vision, HDR10+ and HLG Support
• HDCP 2.2 (and all earlier versions supported)
• Simple setup with front panel control screen
• WebOS for simple connectivity and control/management
• Ultra-Low Profile (1U)
• Fast Switching
• Advanced EDID Management
• IR, RS-232 and LAN Control Options
• Digital Coax Audio Out (6CH PCM, DD, DTS)
• Driver Support for Crestron, C4, RTI, ELAN and more!!!
• Extracted Audio Now Has 3 Operating Modes. Bound to Input, Bound to Output, or Independent Matrix

4

Whats in the box?
• AC-MX1616-AUHD (Matrix Switch)
• Operating Instructions
• 48V Power Supply
• 1 x IR Remote Control
• 1 x IR Extension Cable

________________________________________

Resources
