AC-SW62-UHD_9G

Pridal: Pridané: 17.3.2017 04:45:00 Počet zobrazení: 292

17 Marec 2017

prinášame multivstupový (3*HDMI, 1*DP, 1*VGA, 1*HDBaseT) maticový prepínač s multi výstupom (1*HDMI a 1*HDBaseT-Lite), obmedzene podporuje HDMI2.0a svojou podporou TMDS Clock 340MHz, s dátovým tokom 10.2Gbps, plnou podporou HDCP2.2...

AC-SW62-UHD_9G

AC-SW62-UHD
• DispayPort & VGA Inputs
• HDBaseT_100m Input (w/ PoE for Wall Plate Transmitter)
• HDMI2.0a & HDBaseT-Lite_70m Matrix Outputs
• UHD/4K*30 4:4:4, UHD/4K*60 4:2:0 (HDMI input Only)
• HDR 4:2:2 12 Bit Support (HDMI input Only)
• HDCP 2.2 & Earlier Supported
• 100m 0n 1080P, Up to 70m on 4K (Cat.6a) In
• 70m On 1080P, 40m on 4K (Cat.6a) Out
• PoE provider for AC-EX100WPP-UHD-T Wall Plate Tx
• PoE Provider for AV-EX70-UHD-R Receiver
• Fast Switching
• Analog audio extraction
• RS232 & IR Control
• RS232 & IR pass through to HDBaseT-Lite_70m Rx
• Compatible with HDBaseT & HDBaseT-Lite displays, projectors, AVR's
• Designed for the conference/classroom room so your customer can focus on their meetings, not their video system.

AVProConnect's AC-SW62-UHD_9G (aka EasyStreet) is a robust multi-format matrix switch designed for small offices, classrooms and conference rooms. This 6x2 matrix is designed to be an ALL-IN-ONE solution for the active office allowing for multiple input types, including 3*HDMI, 1*VGA, 1*DisplayPort. In addition to the local inputs, it has a 1*HDBaseT_100m input that is compatible with the AC-EX100WPP-UHD so you can use a Wall Plate Transmitter from anywhere in the room, or a separate room all together!

You have two outputs with this matrix, one is HDBaseT_100m (Cat.6A) and the other is HDMI2.0a. Being a matrix, you have the ability to have different sources displayed on two displays at once.

You can use RS232 or IR to control the unit in addition to being able to pass RS232 and IR signals to the the remote end over the HDBaseT-Lite_70m output. Analog audio extraction is also available for a zoned or local audio system.

Simple, intuitive and automatic control makes this unit the ideal "leave in the room" matrix. The user have an "Auto" option where the unit defaults to the last plugged in device, or simple one button control for each output. Efficiency is the name of the game with this matrix switch.
________________________________________

Key benefits of using AC-SW62-UHD:

1) ULTRA HIGH DEFINITION: This unit supports UHD/4K resolutions for today's modern office. As displays get larger and PC's output more UHD/4K content, UHD/4K is ever more necessary in this environment. Utilizing high resolution allows the user to share higher quality marketing and draft images and makes presentations sharper and view-able for larger audiences.

2) DISTANCE: By using AC-EX100WPP-UHD-T, the transmission distance for FullHD is 100 m & UHD/4K is up to 70 m into the matrix! You can additionally go 70m on FullHD, 40m on UHD/4K from the HDBaseT-Lite output to a display.

3) AUTO SENSING: This matrix is designed to be a "Set it & forget it" piece of hardware. When the user plugs in their device (BYOD), the matrix automatically senses the signal and makes it active. If more than one inputs are in use, there is a simple button on the front to toggle inputs for each output.

4) CONTROL: Simple front panel control, IR and RS232 control is available.

5) POWER: The EasyStreet is capable of powering both the HDBaseT_100m input device or transmitter (AC-EX100WPP-UHD or AC-EX100-UHD-T) as well as the HDBaseT-Lite_70m receiver (AC-EX70-UHD-R). This eliminates unnecessary power supplies and cleans up the installation dramatically.

6) MULTI-FORMAT: The Multi-format design allows you to leave this "in-room" matrix comfortable without having to supply a plethora of adapters. You have input options for VGA, DisplayPort, and 3x HDMI. In addition if you use the AC-EX100-WPP Transmitter, you have another HDMI and VGA input.
________________________________________
AC-SW62-UHD Applications
• The efficient user interface makes it an ideal "leave in room" device for conference rooms that the end user can control simply.
• Conference/huddle room configurations where many sources types can be used, DisplayPort, HDMI and VGA
• HDBaseT_100m In and HDBaseT-Lite_70m Out for large auditorium type scenarios.
• Lecture halls and instructor led classrooms where the instructor can have total control of remote and local inputs
• Auto sensing, so the end user has ZERO configuration
• In-Home media rooms with one or two displays and a need for multiple, fast switching , inputs
• Anywhere where a reliable, simple to use switch is necessary.
Diagrams:

ac-sw62-uhd_9G

________________________________________
Full Feature Set Specifications
• 3x HDMI 2.0a Inputs
• DispayPort & VGA Inputs
• HDBaseT_100m Input (w/ PoE for Wall Plate Transmitter)
• HDMI2.0a & HDBaseT-Lite Matrix Outputs
• 4K*30 4:4:4, 4K*60 4:2:0 (HDMI2.0a input Only)
• HDR 4:2:2 12 Bit Support (HDMI2.0a input Only)
• DCI 2K, 1080P, 1920x1080x60 (VGA Support)
• 4K*30 4:4:4, 4K*60 4:2:0 (DisplayPort)
• HDCP 2.2 & Earlier Supported
• 100m 0n 1080P, Up to 70m on UHD/4K (Cat.6a) In
• 70m On 1080P, 40m on UHD/4K (Cat.6a) Out
• PoE provider for AC-EX100WPP-UHD-T Wall Plate Tx
• PoE Provider for AV-EX70-UHD-R Receiver
• Fast Switching
• Plug & Play auto input sensing
• Simple "One-touch" front panel controls
• Analog audio extraction
• RS232 & IR Control
• RS232 & IR pass through to HDBaseT Rx
• Compatible with HDBaseT displays, projectors, AVR's
• Designed for the conference/classroom room so your customer can focus on their meetings, not their video system.
• Supports uncompressed PCM 2- Ch., 5.1, 7.1, Dolby Digital, DTS, Dolby TrueHD, DTS HD-Master Audio, Atmos.
In The Box AC-SW62-UHD
• AC-SW62-UHD (Matrix)
• IR Emitter
• IR Receiver
• Mounting Ears
• 4 ~ 3-pin terminal plugs
• 1 ~ 5-pin terminal plug
• 48V Power Supply
• Operating Instructions
________________________________________
